Intelligent Video Traffic Monitoring for Self-Adaptive Traffic Signal Control System
Cities consist of roads and streets where all types of vehicles: pedestrian, bicycles, cars, and buses intersect. Traffic signal controls at intersections highly impact vehicle activity, conflicting movement and capacity. To achieve an effective transportation solution that maintains safety but also permits better traffic throughput, accurate traffic monitoring is needed to understand vehicle movements and flows throughout the city.
Traditional detection methods like ultrasonic, microwave radar, or infrared sensors either cost too much to deploy or lack the necessary recording detail. Video detection systems can overcome these disadvantages and can, with artificial intelligence (AI), generate essential traffic metadata. Information such as vehicle numbers, direction, waiting times etc. can all easily be acquired using video equipped with edge-based AI systems. It is a revolution in traffic monitoring.
The AI traffic monitoring solution included a self-adaptive traffic light system, edge AI system, and a backend AI inference server; all integrated into a carefully designed dataflow. The edge AI system grabs video streams from the IP cameras and then analyzes the content using inference. Power-over-Ethernet (PoE) supplies power to the IP cameras through a general purpose RJ45 LAN port, which makes it much easier to deploy cameras in remote areas. Low power consumption, fanless design, and wide-temperature functions were necessary to meet the requirement as a road-side system since the equipment would be hung on traffic signal structures to control traffic lights.
monitoring is completed at the road-side, the raw data will be transmitted back
to the central control room. The AI inference server leverages high processing
power to meet the massive inference processing requirements and to be able to analyze
the set of metadata via pre-trained deep learning models. Then, the
self-adaptive traffic lights can be managed from the traffic center control
Integrated with an
intuitive dashboard in the control room, the SKY-6100 AI inference server not
only receives metadata from all edge AI systems but also monitors all traffic
conditions through deep learning models. If any abnormal situations occur, the
AI server can recognize it and manage the traffic lights adaptively. Through
the analytic power of SKY-6100, the self-adaptive traffic signal control system
makes the traffic in the city flow smoothly and efficiently. Now, the city
government can have a high-level overview of all traffic in the city in real
time. Moreover, traffic data and information are constantly needed to assess
current and past performance and to predict future performance. All this helps pro-active
transportation planning such as traffic impact assessments, public
transportation, and road design to make a better future transportation infrastructure.
- AI traffic monitoring solution with a well-designed end-to-end data flow.
- Industrial edge AI system empowers AI computing at the road-side with minimum deployment effort.
- Deep learning computing at the back-end permits self-adaptive traffic light control
To fulfill real-time traffic monitoring applications and self-adaptive traffic light control, a well-designed end-to-end dataflow is crucial. However, lots of traffic monitoring systems in the market are focusing on vehicle recognition and object counting but lack raw metadata transformation to make solutions practical. Advantech provides an AI end-to-end solution and offers full range edge AI systems and AI inference systems, which have sufficient deep learning capabilities to perform AI inference.
The industrial grade MIC-7200 takes advantage of NVIDIA JETSON features to implement AI at the road-side.
SKY-6100 1U rackmount server supports up to 5x state-of-the-art NVIDIA TESLA P4 to analyze large-scale AI.
